Structural Analysis using ANSYS FEA for Engineering Applications

Topic:Engineering

Course Type:Short & Modular Courses

Register interest
Download PDF for print

Overview

  • Course Date:

    14 Mar 2022 to 16 Mar 2022
  • Registration Period:

    06 Dec 2021 to 21 Feb 2022
  • Time:

    09:00 AM to 06:00 PM,
    24 hours / 3 days
  • Mode of Training:

    Classroom
  • Venue:

    Singapore Polytechnic
  • Funding:

    Eligible for SkillsFuture Credit

This short course is to allow the participants to appreciate structural analysis with commercial (ANSYS) Finite Element Analysis (FEA) software for solving engineering problems with practical session to enhance the learning outcome. In addition, simulation training with lab practical testing session are not common in other training providers. This lab practical session will be conducted and is linked to the analysis simulation.

Ansys Structural Analysis

Course Objective

By the end of the course, participants will be able to:

1. Explain the principles of Finite Element Analysis (FEA)
2. Apply the FEA using commercial ANSYS FEA software to solve structural problems

Course Outline

Introduction to FEA
• Geometry preparation
• Pre-processing, Structural analysis, Post-processing
• Best practices and FEA industries applications
• Module 1: CAD Modelling
Workshop 1.1:  CAD Modelling Basic using SpaceClaim
Workshop 1.2:  Sketching in SpaceClaim
• Module 2: Introduction to Mechanical
Workshop 2.1:  Mechanical Basics
• Module 3: Preprocessing
Workshop 3.1:  2D Gear and Rack Analysis
• Module 4: Static Structural Analysis
Workshop 4.1:  Linear structural analysis
• Module 5: Postprocessing, Validation, CAD, and Parameters.
Workshop 5.1:  Mesh Evaluation
Workshop 5.2:  Parameter management

Workshop for FEA Case Study with Hands-on Practical Measurement Session
• Case study 1 Workshop: 3-point bending of beam
• Case study 2 Workshop: Short column bending
• Case study 3 Workshop: Torsional stress
• Case study 4 Workshop: Contact spring force

• Case study 1 Validation Test Measurement: 3-point bending of beam
• Case study 2 Validation Test Measurement: Short column bending
• Case study 3 Validation Test Measurement: Torsional stress
• Case study 4 Validation Test Measurement: Contact spring force
• Correlation of test results to FEA results

Using FEA for Thermal & Modal Analysis
• Module 6: Mesh Control
Workshop 6.1:  Mesh Creation
• Module 7: Thermal
Workshop 7:  Thermal Analysis of a Pump Housing
• Module 8: Modal
Workshop 8.1:  Modal Analysis of a Machine Frame
• Introduction to Non-Linear
• Introduction to Dynamics

Minimum Requirements

Diploma in Engineering with computer-aided design (CAD)  experience

Certification / Accreditation

• Certificate of Attendance (electronic Certificate will be issued)
A Certificate of Attendance will be awarded to participants who meet at least 75% attendance rate

• Certificate of Performance (electronic Certificate will be issued)
A Certificate of Performance will be awarded to participants who pass the assessment and meet at least 75% attendance rate

Structural Analysis using ANSYS FEA for Engineering Application Sample Cert

Suitable for

Designers, Engineers, Engineering/Technical Manager

Course Fees

Full Fees (before GST): $2,400.00

Applicants/Eligibility SkillsFuture Funding GST* Subsidised Fee (after GST)
Singapore Citizens aged 40 and above¹ $ 2,160.00 $57.60 $297.60
Singapore Citizens aged below 40 $1,680.00 $57.60 $777.60
Singapore Permanent Residents and LTVP+ Holders $1,680.00 $57.60 $777.60
SME-sponsored Singapore Citizens, Permanent Residents and LTVP+ Holders² $2,160.00 $57.60 $297.60
Others (Full fees payable) $0.00 $192.00 $2,592.00

*As announced at Budget 2022, there will be no increase in government fees and charges for Singaporeans from 1 Jan 2023 to 31 Dec 2023. Also, as per SSG’s policy, the GST payable for all funding-eligible applicants is calculated based on prevailing GST rate after baseline funding subsidy of 70%

Singaporeans aged 25 years and above may use **SkillsFuture Credit balance to offset respective course fees.

1 Under the SkillsFuture Mid-career Enhanced Subsidy. For more information, visit the SkillsFuture website here
2 Under the Enhanced Training Support for Small & Medium Enterprises (SMEs) Scheme. For more information of the scheme, click here. To view SP’s list of similar funded courses, click here. Please submit the attached “Declaration Form for Enhanced Training Support Scheme for SME” together with your online application.


Funding Incentives

Please click here for more information on funding incentives.


Application Procedure

1. All applications must be made via Online Registration at www.pace.sp.edu.sg
Course fees can be paid by the following payment modes:

a) Credit Cards, Internet Banking, NETS (Not Applicable for company sponsored)
For e-payment using Visa/Master cards and Internet Banking, please click on the ‘Make e-Payment’ button on the acknowledgement page to proceed.

b) For NETS payment, you can pay at:
Singapore Polytechnic
One-Stop Service Centre

c) For payment via PayNow, please enter the UEN No. T08GB0056ACET and indicate the invoice/registration number.

*With effect from 1 August 2021, cheque payment will not be available.

2. All successful applicants will be notified with a letter of confirmation via email.
